RK3588 mini pc - New generation 8k tv box smart digital signage player product

This ARM Mini pc box equipped with RK3588 chip adopts advanced hardware and flexible system configuration, designed to meet various high-performance needs. The following are the detailed configuration and features of this product:

• - Operating system: Supports dual-system startup of Android 12 and Linux Debian 11, the default system is Android 12, and users can choose the appropriate system according to their needs.
• - Wireless network: Built-in 2x2 MIMO dual antenna design, supports Wi-Fi 6 2.4GHz/5.8GHz (PCIe v3.0), providing faster wireless transmission speed and more stable connection.
• - Bluetooth: Supports Bluetooth 5.0, providing more reliable wireless device connection.
• - Processor: Rockchip RK3588, equipped with quad-core ARM Cortex-A76 and quad-core Cortex-A55.
• - Graphics processor: ARM Mali-G610 MP4, suitable for processing high-performance graphics tasks.
• - Neural Network Processor (NPU): 6 TOPS, supports multiple data formats such as int4, int8, int16, FP16, BF16, TF32, etc.
• - Memory: Optional 4GB / 8GB LPDDR4/LPDDR4x (64-bit).
• - Storage: Optional 32GB / 64GB / 128GB / 256GB eMMC 5.0 / 5.1.
• - Interface configuration:

Advantages of dual 1000M Ethernet ports

Dual 1000M Ethernet ports provide higher network flexibility and performance, suitable for the following scenarios:

1. Network load sharing and redundancy: It can connect two independent networks to achieve network load balancing or redundancy, ensuring high availability and stability of the network.
2. Multi-device connection: It supports high-bandwidth transmission of multiple devices at the same time, suitable for environments that need to connect multiple network devices, such as smart homes or small office networks.
3. Enhanced security: One port can be used for external network connection and the other port for internal LAN connection, thus improving network security.

Application scenarios of dual HDMI output and HDMI input

Dual HDMI output and HDMI input provide rich multimedia connection options:

1. HDMI OUT 1 (HDMI 2.1 / 7680x4320 @ 60Hz):

- Application scenarios: Suitable for connecting to 8K monitors or TVs, providing ultra-high-definition visual experience, especially suitable for high-resolution content display, such as home theater or high-end advertising display.

2. HDMI OUT 2 (HDMI 2.1 / 4096x2304 @ 60Hz):

- Application scenarios: Suitable for connecting to 4K monitors, suitable for daily home entertainment, office meetings and other scenarios that require high-definition display.

3. HDMI IN (HDMI 2.0 / HDMI 1.4b, supports 4K x 2K video format):

- Application scenarios: You can connect external video sources such as game consoles and Blu-ray players to input and play high-definition content, enhancing the versatility of the device.

Application of the device in multiple fields

With its multi-core processing capability, powerful graphics processing and AI acceleration capabilities, as well as rich interface and system support, the RK3588 device has shown great application potential in ARM PC, edge computing, AR/VR, NVR, smart vehicles and cloud terminals. Whether it is computing performance, image processing or intelligent requirements, RK3588 can provide efficient and stable solutions for various industries.

1. ARM PC

- Application: The RK3588 chip provides powerful computing power and graphics processing capabilities, making it an ideal choice for building ARM architecture PCs. It supports multiple operating systems such as Android and Linux, suitable for daily office, multimedia processing and developer programming environments.
- Advantages: Low power consumption, high performance and rich interface selection (such as dual HDMI output, Type-C, USB 3.0) enable it to support multi-tasking and multi-monitor configurations.

2. Edge Computing

- Application: With its powerful processing power and 6 TOPS NPU, RK3588 is suitable for edge computing tasks such as real-time data processing, local decision-making of IoT devices, image analysis of smart cameras, etc.
- Advantages: Supporting AI reasoning, it can perform complex machine learning tasks on edge devices, thereby reducing the need to transfer data to the cloud and improving the system's responsiveness and data security.

3. AR/VR

- Applications: RK3588's powerful graphics processing capabilities and HDMI interface that supports 8K video output make it an ideal choice for AR/VR devices. It can provide a smooth immersive experience, support high-resolution display and low-latency operation.
- Advantages: The device's multi-display support and powerful processing capabilities can handle complex 3D rendering and real-time interaction, bringing users a high-quality virtual reality experience.

4. **NVR (Network Video Recorder)**

- Applications: RK3588 is suitable for high-performance network video recording equipment. It supports real-time processing and storage of multi-channel HD camera video streams and is suitable for security monitoring systems.
- Advantages: Dual Gigabit Ethernet ports and a powerful processor enable it to process high-bandwidth video data, while supporting local AI analysis and edge computing functions to improve the intelligence level of the monitoring system.

5. Intelligent Vehicle

- Application: In the field of intelligent vehicles, RK3588 can be used as the core processing unit of the in-vehicle infotainment system, supporting functions such as multimedia playback, navigation, voice control and car networking.
- Advantages: Its low power consumption and high efficiency make it suitable for long-term use in vehicles, while its powerful processing capabilities can support complex image processing and AI algorithms, improving the performance of intelligent driving assistance systems.

6. Cloud Terminal

- Application: RK3588 can be used as a cloud terminal device to access virtual desktops and cloud computing resources. It supports high-resolution display and multi-tasking, suitable for cloud office environments in enterprises.
- Advantages: The powerful NPU supports local AI acceleration, improving the response speed of virtual desktops, and its multi-system support makes the device more flexible in different application scenarios.

Typical usage scenarios

1. High-end home entertainment system
The powerful processing power of the RK3588 chip and support for 4K/8K video decoding make it an ideal choice for home theater systems. The dual HDMI output interface allows multiple displays to be connected at the same time, and the HDMI input interface supports the connection of other video sources. Connect a large-screen TV or projector through the 8K HDMI output to achieve an immersive ultra-high-definition home theater experience; connect secondary display devices through the 4K HDMI output to meet multi-screen needs.

2. Enterprise conference and presentation
Rich interface options (including USB and micro-SD card interfaces) support the connection of external devices and data storage. Use dual HDMI outputs to show different content simultaneously in a meeting, one for the main presentation and the other for reference materials or remote meetings. The HDMI input interface can be connected to external presentation equipment to improve meeting efficiency.

3. Digital signage and advertising playback
Dual Gigabit Ethernet ports and Wi-Fi 6 support ensure the stability and high speed of network connection, as well as smooth playback and fast update of advertising content. The dual antenna design further improves the strength and coverage of wireless signals. Play advertising content simultaneously through 8K and 4K output to attract more audience attention.

4. Multimedia content creation and editing
The high-performance RK3588 chip and NPU support complex multimedia content creation and editing, and support high-speed data transmission and large-capacity storage with USB 3.0 and micro-SD card interfaces. 8K and 4K dual outputs allow creators to preview and edit high-resolution content at the same time.

Summary

This box equipped with the RK3588 chip can meet various high-performance requirements from home entertainment to enterprise applications with its powerful hardware configuration such as dual Gigabit Ethernet ports, dual HDMI outputs (supporting 8K and 4K), and HDMI input. Whether it is ultra-high-definition content playback, conference presentation, or content creation, this box can provide excellent performance and flexible application scenarios.
