Amlogic S905X5M Android TV Box——Advanced 6nm chip, AI-SR

1. The Amlogic S905X5M Android TV Box

The Amlogic S905X5M Android TV Box is packed with modern features for a seamless entertainment experience. Here's a quick overview:

- Processor:
Powered by a quad-core ARM Cortex-A55 CPU for efficient and smooth 4K streaming and multitasking.
- Graphics:
Equipped with a Mali-G31 V2 GPU for enhanced visuals, supporting casual gaming and HDR content.
- Video Playback:
Supports 4K resolution at 60fps with HDR10+ and Dolby Vision for vibrant colors and sharp images. Includes modern codecs like AV1, VP9, H.265, and H.264 for efficient streaming.
- Connectivity:
Features Wi-Fi 6, Bluetooth 5.2, HDMI 2.1, USB 3.0, and Ethernet, ensuring fast and reliable connections with versatile ports.
- Memory and Storage:
Typically offers 4GB RAM and 64GB storage (varies by model) with expandable options via microSD or USB.
- Software:
Runs on the latest Android 14 for a user-friendly interface and access to the Google Play Store.
- Advanced Features:
Includes AI upscaling to improve the quality of lower-resolution content.

This TV Box is perfect for streaming, gaming, and enhancing your smart home setup.

2. Amlogic S905X5M Android TV Box Specs

Value	Amlogic S905X5M Android  TV Box	X96 M200
CPU	Chipset	Amlogic S905X5M
	Architecture	Quad Core ARM Cortex A55
GPU	Chipset	ARM G310 V2
	Architecture	OpenGL ES 3.2, Vulkan 1.2 and OpenCL 2.0 support
RAM	Capacity	4GB   (2/4GB Optional)
ROM	Capacity	64GB  (16/32/64/128GB Optional)
External storage	USB Storage Devices	USB2.0 Support
	Micro SD card	Supported
Software
Operating system	OS Version	Android 14
	Language	Multi-Language
	Video/Picture Decoding	AV1 MP-10@L5.1 up to 4Kx2K@60fps
		VP9 Profile-2 up to 4Kx2K@60fps
		H.265 HEVC MP-10@L5.1 up to 4Kx2K@60fps
		MPEG-4 ASP@L5 up to 1080P@60fps (ISO-14496)
		WMV/VC-1 SP/MP/AP up to 1080P@60fps
		AVS-P16(AVS+) /AVS-P2 JiZhun Profile up to 1080P@60fps
		MPEG-2 MP/HL up to 1080P@60fps (ISO-13818)
		MPEG-1 MP/HL up to 1080P@60fps (ISO-11172)
		Multiple language and multiple format sub-title video support
		MJPEG and JPEG unlimited pixel resolution decoding (ISO/IEC-10918)
		Supports JPEG thumbnail, scaling, rotation and transition effects
	Image Engine	Supports HDR10, HDR10+ processing
		Inline AI-SR,Block noise, mosquito noise, spatial noise, contour noise reduction
	Audio	Supports MP3, AAC, WMA,  FLAC, Ogg.
	Image	HD JPEG、BMP、GIF、PNG、TIF
Network service
Wi-Fi	Type	Support WiFi IEEE 802.11 a/ b / g / n
	Frequency	Support 2.4G and 5G
	Antenna Type	one external antennas
Bluetooth	Bluetooth	Support BT5.X
Interface
Charge	DC connector	DC IN(5V/2A)
Video output	HDMI	4K*2K UHD Output, HDMI 2.1a
IR Reciver	3.5mm Earphone jack	Remote Reciver Connect
Micro SD	External memory	Support
USB port	USB host	*2  USB2.0 normal type
Ethernet	Ethernet	1000M Ethernet
Appearance
Body Material	ABS
Color	Black
Size	106x106x23(mm)
Weight	0.135Kg
Cerifications(For Unit)
Standard	CE	/
	RoHS	/
Others	Optional	/
Package contents		Shipping Info
User manual	*1	Gift Box Dimension(mm)		205*140*50(mm)
Gift Box	*1	Carton Size(mm)		420*270*305 (mm）
Remote control	*1	Qty Per Carton(pcs)		20
HDMI external cable	*1	Gift Box.G.W(gs)		0.388Kg
Power adapter	*1	Export carton (G.W.)(kgs)		8.76Kg

3. What is the difference between S905X5M

Android TV Box and S905X4?

1. CPU & Process Node

• S905X4:

  • CPU: Quad-core ARM Cortex-A55 (up to 1.9–2.0 GHz).

  • Process Node: 12nm (efficient but older fabrication).

• S905X5M:

  • CPU: Quad-core ARM Cortex-A55 (likely clocked slightly higher, e.g., 2.0–2.2 GHz).

  • Process Node: 6nm (newer, more power-efficient, better thermal performance).

Key Difference: The S905X5M’s 6nm design improves energy efficiency and reduces heat, enabling sustained performance in compact devices.

2. AI-SR (AI Super Resolution)

The S905X5M introduces AI-SR, a dedicated AI-driven upscaling technology, which is absent in the S905X4.

• S905X5M:

  • NPU Integration: Equipped with a dedicated Neural Processing Unit (NPU) for AI tasks.

  • AI-SR Functionality: Uses machine learning algorithms to upscale lower-resolution content (e.g., 720p/1080p) to near-4K quality by analyzing textures, edges, and motion. This reduces blur and enhances detail in older or low-bitrate videos.

  • Real-Time Processing: The NPU handles AI tasks independently, freeing up the CPU/GPU for other operations, ensuring smoother performance during upscaling.

  • Adaptive Optimization: Dynamically adjusts sharpness, noise reduction, and color accuracy based on content type (e.g., movies, sports, animations).

• S905X4:

  • No Dedicated NPU: Relies on traditional CPU/GPU-based upscaling, which is less sophisticated and more resource-intensive.

  • Basic Upscaling: Uses simpler algorithms (e.g., bilinear or bicubic interpolation), resulting in softer edges and less detail recovery compared to AI-SR.

Key Difference:
The S905X5M’s AI-SR delivers significantly sharper and more natural upscaling for non-4K content, while the S905X4 lacks advanced AI enhancements.

3. 6nm vs. 12nm Process Technology

The fabrication process is a major differentiator between the two chips:

• S905X5M (6nm Process):

  • Efficiency: The 6nm node (TSMC or similar) packs more transistors into a smaller area, reducing power consumption by ~15–20% compared to 12nm.

  • Thermal Performance: Generates less heat, enabling fanless designs or quieter cooling systems. This also prevents thermal throttling, ensuring sustained peak performance during extended use.

  • Performance Gains: The smaller node allows slightly higher clock speeds (e.g., CPU up to 2.2 GHz vs. 2.0 GHz on S905X4) without sacrificing stability.

• S905X4 (12nm Process):

  • Older Node: Less efficient, leading to higher power draw and heat output.

  • Thermal Limitations: Often requires active cooling (e.g., fans) in TV boxes, which can add noise and bulk.

  • Performance Cap: Lower maximum clock speeds due to thermal constraints.

Key Difference:
The 6nm process in the S905X5M improves energy efficiency, thermal management, and potential performance margins, making it better suited for compact, always-on devices like streaming boxes.

4. Connectivity

• S905X4:

HDMI: 4K*2K UHD Output, HDMI 1.4/2.0

• • Wi-Fi: Support WiFi IEEE 802.11 b / g / n / ac
    Support 2.4G and 5G
    Two external antennas


  • Bluetooth: Support BT4.X

• S905X5M:

  • HDMI:  4K*2K UHD Output, HDMI 2.1a

  • Wi-Fi: Support WiFi IEEE 802.11 a/ b / g / n
    Support 2.4G and 5G
    one external antennas

  • Bluetooth: Support BT5.X



4. Why Choose the Amlogic S905X5M Android TV Box?

The Amlogic S905X5M Android TV Box stands out as a top choice for those seeking a reliable, high-performance streaming device. Here's why:

1. Powerful Performance
   Equipped with a quad-core ARM Cortex-A55 CPU and Mali-G31 V2 GPU, this TV Box delivers smooth 4K playback, responsive multitasking, and great graphics for casual gaming and media use.

2. Future-Ready AV1 Decoding
   With support for AV1, the latest video compression technology, you can stream high-quality content with lower bandwidth, ensuring compatibility with platforms like YouTube and Netflix.

3. Stunning Visuals
   Enjoy 4K resolution at 60fps with HDR10+ and Dolby Vision for rich colors, deep contrasts, and cinematic viewing.

4. Efficient 6nm Chipset
   The modern 6nm chipset ensures excellent performance while being energy-efficient and generating less heat, perfect for sustainable and uninterrupted streaming.

5. Versatile Connectivity
   Boost your connectivity with Wi-Fi 6, Bluetooth 5.2, HDMI 2.1, USB 3.0, and Ethernet support for fast and stable connections across a variety of devices.

6. Latest Android 14 OS
   Enjoy the intuitive interface, enhanced security, and new features offered by Android 14, along with full access to Google Play Store apps.

7. AI Upscaling Technology
   Improve the quality of low-resolution content with AI upscaling, delivering sharper visuals for older videos.

8. Expandable Storage Options
   With ample RAM, built-in storage, and support for expandable memory via microSD cards or USB, you'll never run out of space for apps, movies, or music.

9. All-in-One Entertainment Device
   Whether you're streaming movies, playing games, or creating a smart home hub, the Amlogic S905X5M TV Box satisfies all your entertainment needs.

If you are interested in Amlogic S905X5M Android TV Box, we have released the latest X96 M200 TV Box, please contact us for details——X96 TV Box Manufacturer
