X98H 4K Android Allwinner H618 WiFi6 tv box
X98H 4K Android Allwinner H618 WiFi6 tv box
The X98H is a 4K Android TV Box powered by the Allwinner H618 processor and features WiFi 6 for faster and more reliable wireless connectivity. Here's a breakdown of its key features:
Processor:
- Allwinner H618: A powerful quad-core processor designed for smooth 4K video playback and general usage. It offers sufficient performance for streaming, gaming, and other multimedia tasks.
Operating System:
- Android: The X98H runs on the Android operating system, providing access to a vast library of apps, games, and streaming services.
Video Playback:
- 4K Resolution: Supports 4K video playback, delivering crisp and detailed visuals for your favorite movies and shows.
Connectivity:
- WiFi 6: Equipped with WiFi 6 technology, offering faster speeds and more stable connections compared to older Wi-Fi standards.
- Other Connectivity: Likely includes HDMI output for connecting to your TV, USB ports for external storage, and an Ethernet port for a wired connection.
Additional Features:
- Bluetooth: support Bluetooth connectivity for connecting wireless headphones, keyboards, or mice.
- Voice Control: support voice control
Summary:
The X98H is a feature-rich 4K Android TV Box designed to deliver a smooth and enjoyable entertainment experience. Its powerful processor, 4K video support, and WiFi 6 connectivity make it a good choice for streaming, gaming, and accessing various multimedia content.
| Basic parameters X98H | ||||
| CPU | Chipset | Allwinner H618 | ||
| Architecture | Quad core ARM Cortex A53 | |||
| GPU | Chipset | Mali G31 MP2 | ||
| RAM | Capacity | 4GB (2GB Optional) | ||
| ROM | Capacity | 32GB (16GB Optional) | ||
| External storage | USB Storage Devices | Supported | ||
| Software | ||||
| Operating system | OS Version | Android 12 | ||
| Language | Multi-Language | |||
| Multimedia | Video | Video Decoder: | ||
| H265 Main10@L5. 1 decoder up to 4K@60fps or 6K@30fps | ||||
| VP9 Profile 2 decoder up to 4K @ 60fps | ||||
| AVS2 Jizhun 10bit decoder up to 4K @ 60fps | ||||
| H.264 BP/MP/HP@L4.2 decoder up to 4K@30fps | ||||
| Multi-format 1080p @ 60fps video playback formats ,including H.264 BP/MP/HP , H 263 BP , VP8 , MPEG-1 MP/HL ,MPEG-2 MP/HL , MPEG-4 SP/ASP @ L5 , AVS +/AVS JizhunWMV9/VC1 , etc | ||||
| Video encoder: | ||||
| H.264 BP/MP/ HP encoder up to 4K@25fps or 1080p @ 60fps JPEG snapshot performance of 1080p @ 60fps | ||||
| Audio | MP3, AAC, WMA, FLAC, Ogg. | |||
| Image | HD JPEG、BMP、GIF、PNG、TIF | |||
| Network service | ||||
| Wi-Fi | Type | IEEE802. a/b/g/n/ac /ax | ||
| Frequency | 2.4GHZ , 5.8GHZ | |||
| Antenna Type | Inside antennas | |||
| Bluetooth | Bluetooth | BT5.0+ | ||
| Interface | ||||
| Charge | DC connector | DC 5V- 2A | ||
| Video output | HDMI | 1* 4K 2K Output, HDMI 2.0a | ||
| CVBS | Support PAL/NTSC | |||
| Audio | OPTCAL | 1 * SPDIF | ||
| Ethernet | Ethernet | 1*Default 100M( optional 1000M) | ||
| TF Card | External memory | 1* TF Card | ||
| USB port | USB Host | 3 * USB 2.0 | ||
| Upgrade | KEY | Update firmware | ||
| Others | RTC | Optional | ||
| Appearance | ||||
| Body Material | Plastic | |||
| Color | Black | |||
| Size | 106x106x19mm | |||
| Weight | 0.14 | |||
| Cerifications(For Unit) | ||||
| Standard | CE | / | ||
| RoHS | / | |||
| Others | Optional | / | ||
| Package contents | Shipping Info | |||
| User manual | *1 | Gift Box Dimension(mm) | 205*140*50(mm) | |
| Gift Box | *1 | Carton Size(mm) | 420*270*305 (mm） | |
| Remote control | *1 | Qty Per Carton(pcs) | 20pcs | |
| HDMI external cable | *1 | Gift Box.G.W(gs) | 0.4Kg | |
| Power adapter | *1 | Export carton (G.W.)(kgs) | 8.9Kg | |
