X96mini TV Box
X96 X5 Allwinner H313 Android 10 4K UHD TV Box
X96 X5 Allwinner H313 Android 10 4K UHD TV Box
- Powered by the Allwinner H313 quad-core ARM Cortex-A53 CPU, providing smooth and efficient multitasking capabilities.
- Features the G31 GPU with support for OpenGL 3.2, OpenGL ES 1.1/2.0/3.2, OpenCL 2.0, and Vulkan 1.1, ensuring high-quality graphics and an immersive gaming experience.
- Available with 1.5GB of RAM, with optional configurations of 1GB or 2GB, catering to different user needs and preferences.
- Comes with 8GB of internal storage, with options for 8GB or 16GB, and supports external USB storage devices, allowing users to easily expand their storage capacity.
- Runs on Android 10, providing access to the latest apps and features for an enhanced user experience.
- Offers multi-language support, making it accessible and user-friendly for a global audience.
- Provides a high-value option for streaming, gaming, and multimedia playback, making it ideal for home entertainment setups.
Product Configuration Table
| CPU | Chipset | Allwinner H313 | ||
| Architecture | Quad Core ARM Cotex A53 | |||
| GPU | Chipset | G31 OpenGL3.2 | ||
| Architecture | OpenGL ES 1.1/2.0/3.2，OpenCL 2.0，Vulkan 1.1 support | |||
| RAM | Capacity | 1.5GB (1/2GB Optional) | ||
| ROM | Capacity | 8 GB (8/16GB Optional) | ||
| External storage | USB Storage Devices | Supported | ||
| Software | ||||
| Operating system | OS Version | Android 10 | ||
| Language | Multi-Language | |||
| Multimedia | Video | Amlogic Video Engine (AVE) with dedicated hardware decoders and encoders | ||
| Support multi-video decoder up to 4K@60fps | ||||
| VP9 Profile-2 up to 4K@30fps | ||||
| H.265 Main10@L5.1 up to 4K@60fps | ||||
| AVS2 JiZhun 10bit Profile up to 4K@60fps | ||||
| H.264 BP/MP/HP@L4.2 up to 4K@30fps | ||||
| H.263 BP up to 1080P@60fps | ||||
| MPEG-4 SP/ASP@L5 up to 1080P@60fps | ||||
| MPEG-2 MP/HL up to 1080P@60fps | ||||
| MPEG-1 MP/HL up to 1080P@60fps | ||||
| Xvid up to 1080P@60fps | ||||
| VP8 up to 1080P@60fps | ||||
| Supports *.mkv,*.wmv,*.mpg, *.mpeg, *.dat, *.avi, *.mov, *.iso, *.mp4, *.rm and *.jpg file formats | ||||
| Audio | Supports MP3, AAC, WMA, RM, FLAC, Ogg and programmable with 7.1/5.1 down-mixing | |||
| Image | HD JPEG、BMP、GIF、PNG、TIF | |||
| Network service | ||||
| Wi-Fi | Type | IEEE 802.11 a/b/g/n/ac/ax | ||
| Frequency | 2.4G & 5.8G | |||
| Antenna Type | Inside antennas | |||
| Bluetooth | BT | BT v5.0 | ||
| Interface | ||||
| Charge | DC connector | 5V/2A | ||
| Video output | HD | 4K*2K UHD Output, HD 2.1 | ||
| USB port | USB host | USB 2.0*2 | ||
| Appearance | ||||
| Body Material | ABS | |||
| Color | Black | |||
| Size | 88.4*88.4*18.6(mm) | |||
| Weight | 0.2Kg | |||
| Cerifications(For Unit) | ||||
| Standard | CE | / | ||
| RoHS | / | |||
| Others | Optional | / | ||
| Package contents | Shipping Info | |||
| User manual | *1 | Gift Box Dimension(mm) | 170*115*55(mm) | |
| Remote control | *1 | Carton Size(mm) | 370*290*250 （mm） | |
| HDMI external cable | *1 | Qty Per Carton(pcs) | 20PCS | |
| USB Charger | *1 | Gift Box.G.W(gs) | 0.171Kg | |
| Type-C USB cable | *1 | Export carton (G.W.)(kgs) | 7Kg | |
