X96mini TV Box
New-Generation 4K Home Entertainment Allwinner H626 TV Box Launch: Android TV 14 OS | Wi‑Fi 6 | AV1 | HDMI 2.1 (TMDS) | CEC | USB 3.1 / USB 2.0 | 1000M Ethernet
New-Generation 4K Home Entertainment Allwinner H626 TV Box Launch: Android TV 14 OS | Wi‑Fi 6 | AV1 | HDMI 2.1 (TMDS) | CEC | USB 3.1 / USB 2.0 | 1000M Ethernet
The next‑generation streaming box built on the Allwinner H626 platform.
As a direct upgrade from the widely adopted H618, the H626 delivers enhanced CPU performance and better power efficiency, while maintaining cost‑effectiveness for high‑volume OTT deployments.
Key specifications that set it apart:
- AndroidTV 14 OS – latest Google TV ecosystem support
- WiFi 6 – faster, more reliable wireless connectivity
- Hardware decoding for AV1, VP9, and H.265 HEVC – ensuring broad codec compatibility and smooth playback at lower bitrates
- Bluetooth voice remote – support Google voice assistant
This combination makes the X96Lite an ideal choice for value‑oriented streaming devices that do not compromise on modern media standards. Whether you are upgrading an existing product line or entering the affordable AndroidTV segment, the H626 platform offers a balanced, future‑ready foundation.
Available now for integration and OEM partnerships.
| Product Model | X96 LITE | Project Status | M.P | |
| A-media ID/Mainboard model | YB1057 | |||
| Basic parameters | ||||
| CPU | Chipset | Allwinner H626 | ||
| Architecture | Quad core ARM Cortex A55 | |||
| GPU | Chipset | Mali G310 | ||
| RAM | Capacity | 2GB (4GB Optional) | ||
| ROM | Capacity | 16GB (32/64GB Optional) | ||
| External storage | USB Storage Devices | Supported | ||
| Software | ||||
| Operating system | OS Version | Android 14 | ||
| Language | Multi-Language | |||
| Multimedia | Video | Video Decoder: | ||
| AV1, H.265 MP, VP9, AVS2, supporting up to 4K@60fps | ||||
| H.264 BL/MP/HP, supporting up to 4K@30fps | ||||
| H.263 BP, MPEG-1/2/4, AVS/AVS+, VP8, XVID, supporting up to 1080P@60fps | ||||
| Video encoder: | ||||
| H.264, supporting up to 4K@25fps | ||||
| Image encoder & decoder： | ||||
| JPEG encoder up to 4K@15fps | ||||
| JPEG decoder up to 1080P@60fps | ||||
| Video Enhance Processor (VEP)： | ||||
| Supports motion adaptive de-interlace | ||||
| Supports 3D temporal noise reduction | ||||
| Supports Film Mode Detetion with Video-On-Film Detection | ||||
| Supports horizontal motion compensate de-interlace for subtitle stabilization | ||||
| Video Output | HDMI : Up to 4K@60fps CVBS ： Up to 720x576 in PAL format Up to 720x480 in NTSC format |
|||
| Audio | MP3, AAC, WMA, FLAC, Ogg. | |||
| Image | HD JPEG、BMP、GIF、PNG、TIF | |||
| Network service | ||||
| Wi-Fi | Type | IEEE802. a/b/g/n/ac/ax (optional) | ||
| Frequency | 2.4GHZ ~ 5.8GHZ | |||
| Antenna Type | Inside antennas | |||
| Bluetooth | Bluetooth | BT5.0+ | ||
| Interface | ||||
| Charge | DC connector | DC 5V- 2A | ||
| Video Output interface | HDMI | 1* 4K 2K Output, HDMI 2.1（TMDS） | ||
| CVBS | Support PAL/NTSC | |||
| Optical | SPDIF | 1 * SPDIF OUT | ||
| Ethernet | Ethernet | 1*Default 1000M( optional 100M) | ||
| TF Card | External memory | 1* TF Card | ||
| USB port | USB Host | 1 * USB 3.0，2 * USB 2.0 | ||
| Upgrade | Button | Update | ||
| Others | RTC | Optional | ||
| Appearance | ||||
| Body Material | Plastic | |||
| Color | ||||
| Size | ||||
| Weight | ||||
| Cerifications(For Unit) | ||||
| Standard | CE | / | ||
| RoHS | / | |||
| Others | Optional | / | ||
| Package contents | Shipping Info | |||
| User manual | *1 | Gift Box Dimension(mm) | 205*140*50(mm) | |
| Gift Box | *1 | Carton Size(mm) | 420*270*305 (mm） | |
| Remote control | *1 | Qty Per Carton(pcs) | 20pcs | |
| HDMI external cable | *1 | Gift Box.G.W(gs) | ||
| Power adapter | *1 | Export carton (G.W.)(kgs) | ||
