Rockchip RK3588 Chip For Digital Signage Player
The Rockchip RK3588: Rockchip’s flagship system-on-chip (SoC) engineered to address the most pressing needs of modern digital signage. Designed with robust computing power, advanced media decoding, and built-in AI capabilities, this chip bridges the gap between raw performance and practical usability, empowering signage players to handle 8K HDR content, synchronize real-time data feeds, integrate touch/ sensor peripherals, and run intelligent features (like audience analytics) with reliability. For digital signage deployments that demand versatility without compromising on stability, the RK3588 stands as a pivotal solution.
Rockchip RK3588 Chip
| ◆ CPU | Chipset | Rockchip RK3588 | ||
| Architecture | Quad-core ARM Cortex-A76 and Quad-core Cortex-A55 | |||
| ◆ GPU | Chipset | ARM Mali-G610 MP4 | ||
| ◆ NPU | Supports | 6 TOPS (Supports int4/int8/int16/FP16/BF16/TF32) | ||
| ◆ RAM | Capacity | 4GB / 8GB (64bit LPDDR4/LPDDR4x) | ||
| ◆ ROM | Capacity | 32G / 64G / 128G / 256G (eMMC5.0/ 5.1) | ||
| ◆ Wi-Fi | Type | IEEE 802.11a / b / g / n / ac /ax | ||
| Frequency | Wi-Fi6 2.4GHZ / 5.8GHZ ( PCIe v3.0) | |||
| Antenna Type | 2T2R | |||
| ◆ Bluetooth | Bluetooth | Bluetooth 5.0 | ||
| ◆ RTC | Support | |||
| ◆ IR | Support | Infrared + BT Voice Remote | ||
| ◆ Power Supply | DC 12V/2A | |||
| ◆ Power Indicator (LED) | Power ON :Blue | |||
| ◆ OS | OS Version | Android 12 | ||
| Language | Multi-Language | |||
| ◆ Video | HDMI OUT 1 | HDMI 2.1 / 7680x4320 @ 60Hz | ||
| HDMI OUT 2 | HDMI 2.1 / 4096x2304@60Hz | |||
| HDMI IN | HDMI 2.0 / HDMI 1.4b 4K x 2K video formats(3840x 2160p @ 24Hz / 25Hz / 30Hz and 4096x2160p@24Hz) | |||
| ◆ Earphone | Supports | 1 * 3.5mm Port | ||
| ◆ Ethernet | Ethernet 1 | 1 * 1000M (RGMII) | ||
| Ethernet 2 | 1 * 1000M | |||
| ◆ TF Card | Supports | 1 * TF Card | ||
| ◆ USB port | USB 1/ USB 3 | 2 * USB 2.0 (Host) | ||
| USB 2 | 1 * USB3.0 (Host) | |||
| Type-C | 1 * Type C 3.0 (Download Port) Supported Devices | |||
| ◆ KEY | 1 * Standby | |||
| 1 * Reset | ||||
| 1 * Update Firmware | ||||
| Product Model | A009 | Product Status | M.P | |
| ◆ Multimedia | Video |
* Real-time video decoder of MPEG-1,MPEG-2,MPEG-4,H.263,H.264,H.265,VC-1,VP9,VP8 MVC,AV1 * MMU Embedded * Multi-channel decoder in parallel for less resolution * H.264 AVC/MVC Main10 L6.0 : 8K@30fps (7680x4320)② * VP9 Profile0/2 L6.1 : 8K@60fps (7680x4320) * H.265 HEVC/MVC Main10 L6.1 : 8K@60fps (7680x4320) * AVS2 Profile0/2 L10.2.6 : 8K@60fps (7680x4320) * AV1 Main Profile 8/10bit L5.3 : 4K@60fps (3840x2160) * MPEG-2 up to MP : 1080p@60fps (1920x1088) * MPEG-1 up to MP : 1080p@60fps (1920x1088) * VC-1 up to AP level 3 : 1080p@60fps (1920x1088) * VP8 version2 : 1080p@60fps (1920x1088) |
||
|
Video Encoder * Real-time H.265/H.264 video encoding * Support up to 8K@30fps * Multi-channel encoder in parallel for less resolution * Dual 16M Pixel ISP with HDR&3DNR |
||||
| Audio |
I2S0 with 8 channels * Up to 8 channels TX and 8 channels RX path * Audio resolution from 16bits to 32bits * Sample rate up to 192KHz * Provides master and slave work mode, software configurable * Support 3 I2S formats (normal, left-justified, right-justified) * Support 4 PCM formats (early, late1, late2, late3) * Support TDM normal, 1/2 cycle left shift, 1 cycle left shift, 2 cycle left shift, right shift mode serial audio data transfer * I2S, PCM and TDM mode cannot be used at the same time |
|||
| Image | HD JPEG、BMP、GIF、PNG、TIF | |||
| ◆ Network Function | Neflix,Chrome,Youtube,Online movies | |||
Digital Signage Player can support the following functions
1. Networking & Positioning
- Supports 4G SIM card for remote networking and stable data transmission.
- Enables RT45 positioning (real-time location and status tracking of the signage device) and Wi-Fi positioning.
2. Content Playback & Display
- Delivers 4K/8K high-resolution content playback.
- Adapts to touch screens and supports screen rotation.
- Compatible with multiple multimedia formats: video, image, and audio.
- Offers multi-language support.
3. Management & Scheduling
- Achieves unified management of devices, content, and timing with flexible timeliness.
- Supports RTC timer switch via API interface.
- Allows setup of customized play schedules.
- Enables remote management, including silent installation (automatic app installation without user intervention).
4. System & Performance
- Features an energy-saving and efficient design.
- Runs on a stable, user-friendly operating system.
- Supports installation and operation of APK files.
5. Interfaces & Expansion
- Provides diverse interface options: HDMI, USB, VGA, etc.
Pros and Cons of Rockchip RK3588 for Digital Signage Players
Pros
1. Strong Computing Power: 8-core CPU (Cortex-A76/A55) handles seamless multitasking—e.g., split-screen 4K playback + real-time data sync (inventory/queue info) + touchscreen integration—without lag.
2. Top-Tier Media Decoding: Natively supports 8K@60fps HDR and all mainstream formats (H.265, AV1), ensuring crisp visuals for large screens or video walls.
3. Built-In AI Capabilities: 6TOPS NPU enables on-device smart features (audience counting, gesture control), ideal for interactive or data-driven signage.
4. Rich Connectivity: Supports dual Gigabit Ethernet, USB 3.0, HDMI 2.1, Wi-Fi 6—adapts to wired/wireless setups and peripherals (sensors, 5G modules).
5. 24/7 Stability: Industrial-grade optimization for continuous operation, reducing downtime in high-demand scenes (transport hubs, hospitals).
Cons
1. Higher Cost: More expensive than entry-level chips (e.g., Allwinner H616), making it overkill for budget 1080p basic displays.
2. Higher Power Consumption: Draws 8–12W under load (vs. 3–5W for low-power alternatives), less suitable for battery-powered or energy-sensitive setups.
3. Steeper Adaptation: Requires more complex software tuning (for AI/peripherals), which may challenge small teams without dedicated tech support.
X96 Rockchip RK3588 Android Digital Signage Player
- High-Performance Processor: Powered by the Rockchip RK3588 octa-core CPU (Cortex-A76 + A55), it delivers strong processing power for smooth multitasking and high-speed operation.
- 8K UHD Resolution: Supports 8K video playback, delivering sharp, vivid visuals and vibrant colors to showcase content in premium quality.
- WiFi 6 Technology: Equipped with the latest WiFi 6, featuring faster speeds, lower latency, and higher efficiency for smooth streaming and stable internet connectivity.
- Dual OS Support: Compatible with Android 12 and Linux Debian 11, allowing you to customize your experience and access a wealth of apps and services.
- Ample Storage and RAM: Offers sufficient storage options and high-speed RAM for quick access to apps, games, and media files, ensuring a lag-free experience.
- Comprehensive Connectivity: Comes with multiple USB ports, HDMI output, Gigabit Ethernet, and Bluetooth 5.0, facilitating peripheral connections and upgrading your entertainment setup.
- Advanced Audio & Video Support: Supports advanced codecs like Dolby Vision, HDR10+, and DTS, delivering an immersive audio-visual experience.
